* The performance values refer to primed pumps (with water at 20°C) with open outlet and vary based on the construction materials.
** Attention: average values of the different materials configurations for ball and ball seat.
Technical Specifications
| Suction connections | G 1 1/2″ f o DN 40 – NPT |
| Delivery connections | G 1″1/4 m o DN 32 – NPT |
| Max flow rate * | 23,5 m3/h |
| Max head * | 20 m |
| Viscosity | up to 150 cps |
| Version | Temperature | Weight (pump without motor) |
| PP | from 0°C to +70°C | 4,5 kg |
| PDVF | from -10°C to +100°C | 5,2 kg |
- Kw 1,5 – HP 2 • Box B3+B5 RPM 2900 • Three-phase 230/400 V • 50/60 HZ • 2 Pole IE3 Protection rating IP55 • Ambient temperature -30°C + 45°C
- Kw 2,2 – HP 3 • Box B3+B5 RPM 2900 • Three-phase 230/400 V • 50/60 HZ • 2 Poli IE3 Protection rating IP55 • Ambient temperature -30°C + 45°C
- Kw 1,5 – HP 2 • Box B3+B5 RPM 2900 • Single-phase • Ambient temperature -30°C + 45°C
- Kw 2,2 – HP 3 • Box B3+B5 RPM 2900 • Single-phase • Ambient temperature -30°C + 45°C
- SINGLEPHASE
- ATEX
- NEMA 145 TC (only pump available, with American flange, for coupling with NEMA motor – the motor is not available in our standard)
IMPELLER: | Motor 1,5 Kw
(2 HP) | Motor 2,2 Kw
(3 HP) |
Ø 123 mm (Standard) | up to 1,1 g/cm3 | up to 1,8 g/cm3 |
Ø 108 mm | up to 1,6 g/cm3 | up to 2 g/cm3 |
Ø 90 mm | up to 2 g/cm3 | up to 2 g/cm3 |
- Pump with 1,5 Kw motor
Protective polyurethane foam wrapping in a wooden crate – dimensions cm 58 x 28 x 42 – Weight 10 Kg - Pump with 2,2 Kw motor
Protective polyurethane foam wrapping in a wooden crate – dimensions cm 64 x 28 x 42 – Weight 10 Kg
The weight refers to the package only, without the pump
– KITFLANG-DM15P (PP pump)
– KITFLANG-DM15F (PVDF pump)
