* The performance values refer to primed pumps (with water at 20°C) with open outlet and vary based on the construction materials.
** Attention: average values of the different materials configurations for ball and ball seat.
Technical Specifications
| Suction connections: | G 1 1/2″ f o DN 40 – NPT |
| Delivery connections: | G 1″ m o DN 25 – NPT |
| Max flow rate * | 13 m3/h |
| Max head * | 14 m |
| Viscosity | up to 150 cps |
| PP | 0°C to +70°C |
| PDVF | -10°C to +100°C |
| Version | Temperature | Weight (pump without motor) |
| PP | from 0°C to +70°C | 2,2 kg |
| PDVF | from -10°C to +100°C | 2,5 kg |
- Kw 0,55 – HP 0,75 • Box B3+B5 RPM 2900 • Three-phase 230/400 V • 50/60 HZ • 2 Pole IE1 Protection rating IP55 • Ambient temperature -30°C + 45°C
- Kw 0,75 – HP 1 • Box B3+B5 RPM 2900 • Three-phase 230/400 V • 50/60 HZ • 2 Pole IE3 Protection-rating IP55 • Ambient temperature -30°C + 45°C
- Kw 0,55 – HP 0,35 • Box B3+B5 RPM 2900v • Single-phase • Ambient temperature -30°C + 45°C
- Kw 0,75 – HP 1 • Box B3+B5 RPM 2900 • Single-phase • Ambient temperature -30°C + 45°C
- SINGLE-PHASE
- ATEX
- NEMA 56C or NEMA 143 TC (only pump available, with American flange, for coupling with NEMA motor – the motor is not available in our standard)
IMPELLER: | Motor 0,55 Kw (3 HP) | Motor 0,75 Kw (4 HP) |
Ø 98 mm (Standard) | up to 1,1 g/cm3 | up to 1,5 g/cm3 |
Ø 85 mm | up to 1,6 g/cm3 | up to 2 g/cm3 |
Ø 70 mm | up to 2 g/cm3 | up to 2 g/cm3 |
- Pump with 0,55 Kw motor
Protective polyurethane foam wrapping in a wooden crate – dimensions cm 50 x 25 x 35 – Weight 7 Kg - Pump with 0,75 Kw motor
Protective polyurethane foam wrapping in a wooden crate – dimensions cm 55 x 28 x 42 – Weight 10 Kg
The weight refers to the package only, without the pump
– KITFLANG-DM10P (PP pump)
– KITFLANG-DM10F (PVDF pump)
