Electric centrifugal pumps

DM 06

• Max flow rate: 7 m3/h
• Suction connections: G 1″ f o DN 25
• Delivery connections: G 3/4″ m o DN 20
•

• DATA

  Performance






  * The performance values refer to primed pumps (with water at 20°C) with open outlet and vary based on the construction materials.

  ** Attention: average values of the different materials configurations for ball and ball seat.

  DATA

  Technical Specifications

  Technical Specifications

  Suction connections	G 1″ f o DN 25 – NPT
  Delivery connections	G 3/4″ m o DN 20 – NPT
  Max flow rate *	7 m3/h
  Max rate *	8,5 m
  Viscosity	up to 150 cps

  Operating temperature

  Version	Temperature	Weight (pump without motor)
  PP	from 0°C to +70°C	2 Kg
  PDVF	from -10°C to +100°C	2,25 Kg

  Standard electric motors

  • Kw 0,25 – HP 0,35 • Box B3+B5 RPM 2900 • Three-phase 230/400 V • 50/60 HZ • 2 Pole IE1 Protection rating IP55 • Ambient temperature -30°C + 45°C
  • Kw 0,37 – HP 0,5 • Box B3+B5 RPM 2900 • Three-phase 230/400 V • 50/60 HZ • 2 Pole IE1 Protection rating IP55 • Ambient temperature -30°C + 45°C
  • Kw 0,25 – HP 0,35 • Box B3+B5 RPM 2900 • Single-phase • Ambient temperature -30°C + 45°C
  • Kw 0,37 – HP 0,35 • Box B3+B5 RPM 2900 • Single-phase • Ambient temperature -30°C + 45°C

  Electric motors available on request

  • SINGLE-PHASE
  • ATEX
  • NEMA 56C (only pump available, with American flange, for coupling with NEMA motor – the motor is not available in our standard)

Available in the following materials

Seal o-ring materials

Package

FLANGE KIT (DIN standard – ANSI available on request)
