* The performance values refer to primed pumps (with water at 20°C) with open outlet and vary based on the construction materials.
** Attention: average values of the different materials configurations for ball and ball seat.
Technical Specifications
| Suction connections | G 2″ 1/2 f o DN 65 available on request |
| Delivery connections | G 2″ m o DN 50 available on request |
| Max flow rate * | 75 m3/h |
| Max head * | 38 m |
| Viscosity | up to 500 cps |
| Standard open impeller | Ø 176 mm H 13 mm – 10° (special versions are available on request for the fluid pumped) |
| Passing solids | Ø max 11 mm |
| Available column lenght (mm) | PP pump weight * | PVDF pump weight * |
| 500 | 31 kg | 33 kg |
| 800 | 34 kg | 36 kg |
| 1000 | 36 kg | 38 kg |
| 1250 | 39 kg | 41 kg |
| 1400 ** | – | – |
* The weights refer to the pump without the motor
** Special version
| Version | Min | Max |
| PP | 0° C | 70° C |
| PVDF | -10° C | 100° C |
- Kw 11 – HP 15
- Box B5
- RPM 2900
- Aluminium / cast iron motor (the motor weight may vary, contact the sales office)
- THREEPHASE 230/400 V · 50/60 Hz · 2 pole · Efficiency class IE3 · Protection rating IP55 · Ambient temperature -30°C + 45°C
- Protective cover in polyurethane foam contained in a wooden cage
The dimensions and weights vary according to the length of the pump
- FLANGE KIT (DIN standard – ANSI available on request)
– KITFLANGIM180P (PP pump)
– KITFLANGIM180F (PVDF pump) - Pump protection filter* in PP or in PVDF
* The filter is sold separately
